Impresora Ricoh MP 6055

Internal Shift Tray SH3070

• The Internal Shift Tray enables the system to output copies as sets in sequential order. Each time the copies of one set or a job are delivered, the next copy is shifted to separate each set or job.

• Holds 250 sheets of 8.5″ x 11″ /A4 or smaller and holds 125 sheets of 8.5″ x 14″ or larger.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 3.1 lbs. (1.4 kg)

• W x D x H (inches): 16.5 x 19.3 x 4.2

• W x D x H (mm): 419 x 490 x 107

Notes:

Internal Shift Tray SH3070 cannot be installed with Internal Finisher SR3130, Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, Booklet Finisher SR3240, or any related options.

Punch Unit PU3050 NA

• Optional hole punching for the Finisher SR3210 or Booklet Finisher SR3220.

• Supports Paper Sizes up to 11″ x 17″.

Notes:

1. Finisher SR3210 or Booklet Finisher SR3220 is required to for this option.

2. Punch Unit PU3050NA cannot be installed with the Internal Finisher SR3130 or Internal Finisher SR3180.

Punch Unit PU3060

• Optional hole punching unit for Finisher SR3230, Booklet Finisher SR3240, Finisher SR4120 or Booklet Finisher SR4130.

Notes:

1. One of the following finishers is required to add this option: Finisher SR3230, Booklet Finisher SR3240, Finisher SR4120 or Booklet Finisher SR4130.

2. This option cannot be installed with Finisher SR4080.

Punch Unit PU3040 NA

• Optional hole punching for the Internal Finisher SR3130.

• Supports Paper Sizes up to 11″ x 17″.

Notes:

1. SR3130 is required to add this option.

2. Punch Unit PU3040 NA cannot be installed with the Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, or Booklet Finisher SR3240.

Finisher SR3210

• 1,000-sheet Finisher.

• For offices that produce collated and stapled sets of documents, the SR3210 helps shorten production time. It offers 50-sheet, multi-position stapling, mixed sized stapling, optional hole-punching, and shift-sort collating, as well as a staple-less binding capability of up to 5 sheets.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 60 lbs. (27 kg)

• W x D x H (inches): 22.2 x 24.4 x 37.8

• W x D x H (mm): 564 x 620 x 960

Notes:

1. Bridge Unit BU3070 is required to add this option.

2. Finisher SR3210 cannot be installed with these options: Internal Shift Tray SH3070, Internal Finisher SR3130, Finisher SR3230, Booklet Finisher SR3220, Booklet Finisher SR3240, or any related options.

Booklet Finisher SR3220

• 1,000-sheet Booklet Finisher.

• Allows documents to be professionally finished as paginated, saddle-stitched booklets. It provides three destinations for output, and offers optional hole-punching. Ideal for the production of program guides, instruction sheets, newsletters, and meeting agendas.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 87.3 lbs. (40 kg)

• W x D x H (inches): 22.2 x 24.4 x 37.8

• W x D x H (mm): 564 x 620 x 960

Notes:

1. The Bridge Unit BU3070 is required to add this option.

2. Booklet Finisher SR3220 cannot be installed with these options: Internal Shift Tray SH3070, Internal Finisher SR3130, Finisher SR3210, Finisher SR3230, or any related options.

Finisher SR3230

• 3,000-sheet Finisher.

• For offices that produce collated and stapled sets of documents, the SR3230 helps shorten production time. It offers 50-sheet, multi-position stapling, mixed sized stapling, optional hole-punching, and shift-sort collating.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 74 lbs. (33.5 kg)

• W x D x H (inches): 25.9 x 24.1 x 37.8

• W x D x H (mm): 658 x 612 x 960

Notes:

1. Bridge Unit BU3070 is required to add this option.

2. Finisher SR3230 cannot be installed with these options: Internal Shift Tray SH3070, Internal Finisher SR3130, Finisher SR3210, Booklet Finisher SR3220, Booklet Finisher SR3240, or any related options.

Booklet Finisher SR3240

• 2,000-sheet Booklet Finisher.

• Allows documents to be professionally finished as paginated, saddle-stitched booklets. It provides three destinations for output and offers optional hole-punching. Ideal for the production of program guides, instruction sheets, newsletters, and meeting agendas.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 116 lbs. (52.5 kg)

• W x D x H (inches): 25.9 x 24.1 x 37.8

• W x D x H (mm): 658 x 612 x 960

Notes:

1. Bridge Unit BU3070 is required to add this option.

2. Booklet Finisher SR3240 cannot be installed with these options: Internal Shift Tray SH3070, Internal Finisher SR3130, Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, or any related options.

One-Bin Tray BN3110

• Provides an additional output tray above the standard Internal Tray or optional Bridge Unit/Internal Shift Tray/Internal Finisher.

• Holds 125 sheets.

• Allows user to separate print/fax output from copy.

• Supports paper sizes up to 11″ x 17″.

• Weight: 3.1 lbs. (1.4 kg)

• W × D × H (inches): 17.5 × 17.7 × 5.9

• W × D × H (mm): 445 × 450 × 150

Bridge Unit BU3070

• A required accessory when the main unit is configured with an external finisher. The Bridge Unit transports pages from the standard exit area into a Finisher for online stapling or hole-punching.

Notes:

One of the following finishers is required to add this option: Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, or Booklet Finisher SR3240.

Internal Finisher SR3130

• 500-sheet Internal Finisher provides multi-position stapling and optional hole-punching.

• Recommended for offices with limited floor space.

• Supports Paper Sizes up to 12″ x 18″.

• Weight: 28.2 lbs. (12.8 kg)

• W × D × H (inches): 21.5 × 20.6 × 6.7

• W × D × H (mm): 546 × 523 × 170

Notes:

Internal Finisher SR3130 cannot be installed with MP C6004ex, MP C6004ex TE, Internal Shift Tray SH3070, Internal Finisher SR3180, Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, Booklet Finisher SR3240, or any related options.

Internal Multi-Fold Unit FD3000

• Multi-fold option that allows for the creation of professionally designed finished documents such as newsletters, brochures, and sales and marketing materials. Folding patterns include Z-Fold, Half-Fold, Outer Tri-Fold and Inner Tri-Fold.

• Weight: 33 lbs. (15 kg)

• W x D x H (inches): 24.1 x 21.9 x 7.3

• W x D x H (mm): 612 x 556 x 185

Notes:

1. Internal Multi-Fold Unit FD3000 cannot be installed with Internal Shift Tray SH3070, Internal Finisher SR3130, or any related options.

2. This option or Bridge Unit BU3070 must be installed when adding the following items: Hybrid Finisher SR3210, Finisher SR3230, Booklet Finisher SR3220, or Booklet Finisher SR3240.

Cabinet Type F

• Provides businesses with a convenient option for the storage of supplies and paper.

• Can only be configured with the standard configuration.

• Weight: 32.3 lbs. (14.7 kg)

• W x D x H (inches): 23.1 x 26.7 x 10

• W x D x H (mm): 587 x 678 x 254

Notes:

Cabinet Type F cannot be installed with Caster Table Type M3, Paper Feed Unit PB3220, Paper Feed Unit PB3240, Paper Feed Unit PB3250 or Paper Feed Unit PB3260.

Paper Feed Unit PB3250

• Provides an additional 550 sheets.

• Paper Sizes up to 12″ x 18″.

• Paper Weights up to 300 g/m².

• Weight: 24 lbs. (10.9 kg)

• W x D x H (inches): 23.1 x 27 x 4.7

• W x D x H (mm): 587 x 686 x 119

Notes:

1. Paper Feed Unit PB3250 cannot be installed with Cabinet Type F, Booklet Finisher SR3220 or any related options.

2. This option must be installed with Caster Table Type M3.

LCIT PB3260

• Provides an additional 2,000 sheets.

• Paper Sizes up to 8.5″ x 11″/A4.

• Paper Weights up to 300 g/m².

• Weight: 48.5 lbs. (22 kg)

• W x D x H (inches): 23.1 x 27 x 9.7

• W x D x H (mm): 587 x 686 x 246

Notes:

LCIT PB3260 cannot be installed with Paper Feed Unit PB3240, Paper Feed Unit PB3250, Caster Table Type M3, or Cabinet Type F.

LCIT RT3030

• Provides an additional 1,500 sheets.

• Paper Sizes up to 8.5″ x 11″/A4.

• Paper Weights up to 80 lb. Bond/166 lb. Index (300 g/m²).

• Weight: 21.6 lbs. (9.8 kg)

• W x D x H (inches): 13.4 x 21.4 x 11.4

• W x D x H (mm): 340 x 544 x 290

Notes:

1. LCIT RT3030 cannot be installed with any of these Paper Bank options: Paper Feed Unit PB3250, Caster Table Type M3, or Cabinet Type F.

2. LCIT RT3030 must be configured with either the Paper Feed Unit PB3240 or PB3260.

Caster Table Type M3

• The caster table must be added to the configuration when the PB3250 Paper Feed Unit is selected. It provides a platform with wheels to easily move the device.

Notes:

1. Paper Feed Unit PB3250 is required for this option.

2. Caster Table Type M3 can only be installed with Paper Feed Unit PB3250.

Paper Feed Unit PB3220

• Provides an additional 1,100 sheets.

• Paper Sizes up to 12″ x 18″.

• Paper Weights up to 80 lb. Bond/166 lb. Index (300 g/m²).

• Weight: 48.5 lbs. (22 kg)

• W x D x H (inches): 23.1 x 27 x 9.7

• W x D x H (mm): 587 x 686 x 246

Notes:

Paper Feed Unit PB3220 cannot be installed with Paper Feed Unit PB3250, Caster Table Type M3, or Cabinet Type F.

Embedded HotSpot Option Type S

• Required to enable HotSpot printing. One year HotSpot printing subscription service.

OCR Unit Type M13

• This function embeds invisible text on scanned images of PDF and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders, and external media (USB/SD Card).

IEEE 802.11a/g/n Interface Unit Type M19

• This option allows you to connect the device to an IEEE 802.11 a/b/g/n wireless LAN.

Notes:

IEEE 802.11a/g/n Interface Unit Type M19 cannot be installed with IEEE 1284 Interface Board Type M19, File Format Converter Type M19, or Extended USB Board Type M19.

File Format Converter Type M19

• Required to convert formats and drag to desktop documents stored via Copy or Print mode.

Notes:

File Format Converter Type M19 cannot be installed with the following options: IEEE 1284 Interface Board Type M19, IEEE 802.11a/g/n Interface Unit Type M19, or Extended USB Board Type M19.

*Exception – The File Format Converter Type M19 can be installed with the following options on the MP C4504ex or MP C6004ex models: IEEE 1284 Interface Board Type M19, IEEE 802.11a/g/n Interface Unit Type M19, or Extended USB Board Type M19.

Extended USB Board Type M19

• Required for printing from USB Type B port.

Notes:

Extended USB Board Type M19 cannot be installed with IEEE 1284 Interface Board Type M19, IEEE 802.11a/g/n Interface Unit Type M19, or File Format Converter Type M19.

IEEE 1284 Interface Board Type M19

• For environments that require parallel connectivity.

• Allows device connection with legacy computer equipment.

Notes:

IEEE 1284 Interface Board Type M19 cannot be installed with IEEE 802.11a/g/n Interface Unit Type M19, File Format Converter Type M19, or Extended USB Board Type M19.

XPS Direct Print Option Type M29

• Allows for direct printing of XPS type file formats.

PostScript 3 Unit Type M29

• PostScript option for customers that require true Adobe® PostScript® for Macintosh and PostScript environments.

• Recommended for printing more complex color and PDF files.

SCR3310 v2 USB Smart Card Reader

• Card Reader only. No cards are provided. Used with Common Access Card (CAC)/Personal Identity Verification (PIV) Authentication Solution.

Notes:

SCR3310 v2 USB Smart Card Reader cannot be installed with NFC Card Reader Type M29.

External USB Keyboard (No Bracket)

• External keyboard for inputting data with either SDK applications or embedded applications.

Notes:

1. External Keyboard Bracket Type M19 is required for this option.

2. External USB Keyboard (No Bracket) cannot be installed with the NFC Card Reader Type M19.

Key Counter Bracket Type M3

• 4-Pin interface used to mount external key counter to MFP.

External Keyboard Bracket Type M3

• This bracket is required for the installation of an External USB Keyboard.

Notes:

1. External USB Keyboard (No Bracket) is required to add this option.

2. External Keyboard Bracket Type M3 cannot be installed with the Smart Card Reader Built-in Unit Type M29.

Optional Counter Interface Unit Type M12

• 20-Pin interface used to attach external key counter or key card device.

NFC Card Reader Type M29

• Used to log in and authenticate users via NFC card. The card reader and its cable will be covered inside the mainframe when this option is attached.

Notes:

NFC Card Reader Type M29 cannot be installed with Smart Card Reader Built-in Unit Type M29 or SCR3310 v2 USB Smart Card Reader.

Smart Card Reader Built-in Unit Type M29

• For use with Ricoh & third party software solutions. The smart card reader and its cable will be covered inside the mainframe when this option is attached. If using another type of card reader be sure reader dimensions do not exceed 63.5mm x 106mm x 22mm in size. Not all card readers may be supported.

Notes:

Smart Card Reader Built-in Unit Type M29 cannot be installed with External USB Keyboard (No Bracket), External Keyboard Bracket Type M3, or NFC Card Reader Type M29.

Fax Connection Unit Type M29

• Enables users to send and receive faxes on a sub MFP via a main MFP. This option is required on both the Main MFP that has the Fax Option Type M29 installed and on the Sub MFP(s) needing remote fax.

Notes:

Fax Option Type M29 is required to add this option.

Fax Option Type M29

• Installation required to enable fax services: 33.6 kbps, approximately 2 second transmission speed, standard JBIG, and standard 320 pages memory. Includes standard Internet Fax (T.37), LAN Fax, IP-Fax (T.38), Fax Forwarding to Email, and Paperless Fax function.

G3 Interface Unit Type M29

• Up to two additional lines can be installed for a maximum total of 3 lines.

Notes:

Fax Option Type M29 is required to add this option.

Fax Memory Unit Type M19 64MB

• Increases fax memory to 4,800 pages and fax resolution to 400 x 400 dpi.

Notes:

Fax Option Type M19 or M20 is required to add this option.
